Water Furnace Aston Advanced 161K064TR141N00D0 Geothermal Heat Pump, 5 Tons, R-410A, Vertical, Upflow, Left Return, 208/230 V, 16.4-23.9 EER, 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) Connection, 1-Phase
Water Furnace Aston Advanced 161K064TR141N00D0 Geothermal Heat Pump, 5 Tons, R-410A, Vertical, Upflow, Left Return, 208/230 V, 16.4-23.9 EER, 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) Connection, 1-Phase
| Amperage Rating | : | 40.5 A (FLA), 47.2 A (MCA) |
| BTU Rating | : | 64,000 BTU/hr |
| Blower Size | : | 11" Diam x 10" W |
| CFM Rating | : | 1,800 CFM |
| Coil Rating | : | 5 Tons |
| Color | : | Off White |
| Compressor Type | : | Dual Capacity Scroll |
| Configuration | : | Vertical, Upflow, Left Return |
| Connection Type | : | 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) |
| Dimensions | : | 58-2/5" H x 25-3/5" W x 31-3/5" D |
| Drive Type | : | Direct Drive |
| EER Rating | : | 16.4-23.9 EER |
| Filter Size | : | 36" x 30" x 2" |
| Finish | : | Powder Coated (1,000 Hour Salt Spray Rated) |
| Flow Rate | : | 16 GPM |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 70 A |
| HP Rating | : | 1 HP (Blower Motor) |
| Material | : | Galvanized Steel (Cabinet), Copper (Coil Inner Tube), Steel (Coil Outer Tube) |
| Model | : | 161K064TR141N00D0 |
| Mounting Type | : | Vertical |
| Number of Stages | : | 2 |
| Phase | : | 1 |
| Pressure Rating | : | 464.7 PSI (Working Water), 614.7 PSI (Working Refrigerant) |
| Refrigerant Type | : | R-410A |
| Series | : | Aston Advanced |
| Temperature Rating | : | 50-110 °F (Entering Air, Cooling), 40-80 °F (Entering Air, Heating), 30-120 °F (Entering Water) |
| Tonnage | : | 5 tons |
| Voltage Rating | : | 208/230 V |
The Aston Series utilizes environmentally safe R-410A refrigerant and includes scroll compressors—the most durable and efficient compressor technology. Dual capacity operation provides the finest in comfort and energy savings. And with the Aurora family of controls, you'll have two-way communication, and one of the most efficient dual stage geothermal heating and cooling units to date.This 5-ton vertical unit delivers up to 64,000 BTU/hr heating/cooling capacity with a variable-speed ECM blower motor for consistent airflow up to 1,800 CFM. It operates on 208/230V single-phase power.
Water Furnace Geothermal Heat Pump, Model: Aston Advanced, 5 Tons, R-410A, Vertical, Upflow, Left Return, 208/230 V, 16.4-23.9 EER, 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) Connection, 1-Phase, 58-2/5" H x 25-3/5" W x 31-3/5" D Dimensions, 1,800 CFM, 16 GPM, Direct Drive, Dual Capacity Scroll, 11" Diam x 10" W Blower Size, 1 HP (Blower Motor), Galvanized Steel (Cabinet), Copper (Coil Inner Tube), Steel (Coil Outer Tube), Vertical, 36" x 30" x 2" Filter Size, 2 Stage, 64,000 BTU/hr, 40.5 A (FLA), 47.2 A (MCA), 464.7 PSI (Working Water), 614.7 PSI (Working Refrigerant), 50-110 °F (Entering Air, Cooling), 40-80 °F (Entering Air, Heating), 30-120 °F (Entering Water), 60 Hz, 70 A Fuse Rating, Off White
- Features a durable and efficient two-stage Copeland UltraTechâ„¢ scroll compressor.
- Utilizes environmentally friendly R-410A refrigerant.
- Equipped with a variable-speed ECM blower motor for consistent airflow and comfort.
- Features Aurora Base Controls for advanced system management and communication.
- Constructed with a heavy-gauge galvanized steel cabinet with a durable powder-coat finish.
- Includes an all-aluminum air coil and copper coaxial water-to-refrigerant heat exchanger (Cupronickel option available).
- Offers high efficiency ratings, achieving up to 23.9 EER (Open Loop) or 19.3 EER (Closed Loop).
