Water Furnace Aston Advanced 161K038TR141N00D0 Geothermal Heat Pump, 3 Tons, R-410A, Vertical, Upflow, Right Return, 208/230 V, 17.0-24.4 EER, 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) Connection, 1-Phase
Water Furnace Aston Advanced 161K038TR141N00D0 Geothermal Heat Pump, 3 Tons, R-410A, Vertical, Upflow, Right Return, 208/230 V, 17.0-24.4 EER, 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) Connection, 1-Phase
| Amperage Rating | : | 25.1 A (FLA), 28.9 A (MCA) |
| BTU Rating | : | 38,000 BTU/hr |
| Blower Size | : | 11" Diam x 10" W |
| CFM Rating | : | 1,300 CFM |
| Coil Rating | : | 3 Tons |
| Color | : | Off White |
| Compressor Type | : | Dual Capacity Scroll |
| Configuration | : | Vertical, Upflow, Right Return |
| Connection Type | : | 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) |
| Dimensions | : | 50-2/5" H x 25-3/5" W x 31-3/5" D |
| Drive Type | : | Direct Drive |
| EER Rating | : | 17.0-24.4 EER |
| Filter Size | : | 30" H x 28" W x 2" D |
| Finish | : | Powder Coated (1,000 Hour Salt Spray Rated) |
| Flow Rate | : | 9 GPM (Full Load) |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 40 A |
| HP Rating | : | 1/2 HP (Blower Motor) |
| Material | : | Galvanized Steel (Cabinet), Copper (Coil Inner Tube), Steel (Coil Outer Tube) |
| Model | : | 161K038TR141N00D0 |
| Mounting Type | : | Vertical |
| Number of Stages | : | 2 |
| Phase | : | 1 |
| Pressure Rating | : | 464.7 PSI (Working Water), 614.7 PSI (Working Refrigerant) |
| Refrigerant Type | : | R-410A |
| Series | : | Aston Advanced |
| Temperature Rating | : | 50-110 °F (Entering Air, Cooling), 40-80 °F (Entering Air, Heating), 30-120 °F (Entering Water) |
| Tonnage | : | 3 tons |
| Voltage Rating | : | 208/230 V |
The Aston Series utilizes environmentally safe R-410A refrigerant and includes scroll compressors-the most durable and efficient compressor technology. Dual capacity operation provides the finest in comfort and energy savings. And with the Aurora family of controls, you'll have two-way communication, and one of the most efficient dual stage geothermal heating and cooling units to date.
Water Furnace Geothermal Heat Pump, Model: Aston Advanced, 3 Tons, R-410A, Vertical, Upflow, Right Return, 208/230 V, 17.0-24.4 EER, 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) Connection, 1-Phase, 50-2/5" H x 25-3/5" W x 31-3/5" D Dimensions, 1,300 CFM, 9 GPM (Full Load), Direct Drive, Dual Capacity Scroll, 11" Diam x 10" W Blower Size, 1/2 HP (Blower Motor), Galvanized Steel (Cabinet), Copper (Coil Inner Tube), Steel (Coil Outer Tube), Vertical, 30" H x 28" W x 2" D Filter Size, 2 Stage, 38,000 BTU/hr, 25.1 A (FLA), 28.9 A (MCA), 464.7 PSI (Working Water), 614.7 PSI (Working Refrigerant), 50-110 °F (Entering Air, Cooling), 40-80 °F (Entering Air, Heating), 30-120 °F (Entering Water), 60 Hz, 40 A Fuse Rating, Off White
- Uses environmentally friendly R-410A refrigerant.
- Features a high-efficiency, two-stage scroll compressor for reliable performance and energy savings.
- Equipped with a variable-speed ECM blower motor for precise airflow control.
- Constructed with a heavy-gauge galvanized steel cabinet and powder-coat finish for durability.
- Achieves high cooling efficiency with EER ratings from 17.0 to 24.4.
- Vertical, right-return configuration suits various installation needs.
