Water Furnace Aston Advanced 161J026TR141N00D0 Geothermal Heat Pump, 2 Tons, R-410A, Vertical, Upflow, Left Return, 208/230 V, 16.8-24.0 EER, 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) Connection, 1-Phase
Water Furnace Aston Advanced 161J026TR141N00D0 Geothermal Heat Pump, 2 Tons, R-410A, Vertical, Upflow, Left Return, 208/230 V, 16.8-24.0 EER, 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) Connection, 1-Phase
| Amperage Rating | : | 21.4 A (FLA), 24.4 A (MCA) |
| BTU Rating | : | 26,000 BTU/hr |
| Blower Size | : | 9" Diam x 7" W |
| CFM Rating | : | 950 CFM |
| Coil Rating | : | 2 Tons |
| Color | : | Off White |
| Compressor Type | : | Dual Capacity Scroll |
| Configuration | : | Vertical, Upflow, Left Return |
| Connection Type | : | 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) |
| Dimensions | : | 48-1/2" H x 22-1/2" W x 26-1/2" D |
| Drive Type | : | Direct Drive |
| EER Rating | : | 16.8-24.0 EER |
| Filter Size | : | 28" x 24" x 1" |
| Finish | : | Powder Coated (1,000 Hour Salt Spray Rated) |
| Flow Rate | : | 8 GPM (Full Load) |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 35 A |
| HP Rating | : | 1/2 HP (Blower Motor) |
| Material | : | Galvanized Steel (Cabinet), Copper (Coil Inner Tube), Steel (Coil Outer Tube) |
| Model | : | 161J026TR141N00D0 |
| Mounting Type | : | Vertical |
| Number of Stages | : | 2 |
| Phase | : | 1 |
| Pressure Rating | : | 464.7 PSI (Working Water), 614.7 PSI (Working Refrigerant) |
| Refrigerant Type | : | R-410A |
| Series | : | Aston Advanced |
| Temperature Rating | : | 50-110 °F (Entering Air, Cooling), 40-80 °F (Entering Air, Heating), 30-120 °F (Entering Water) |
| Tonnage | : | 2 tons |
| Voltage Rating | : | 208/230 V |
The Aston Series utilizes environmentally safe R-410A refrigerant and includes scroll compressors—the most durable and efficient compressor technology. Dual capacity operation provides the finest in comfort and energy savings. And with the Aurora family of controls, you'll have two-way communication, and one of the most efficient dual stage geothermal heating and cooling units to date.
Water Furnace Geothermal Heat Pump, Model: Aston Advanced, 2 Tons, R-410A, Vertical, Upflow, Left Return, 208/230 V, 16.8-24.0 EER, 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) Connection, 1-Phase, 48-1/2" H x 22-1/2" W x 26-1/2" D Dimensions, 950 CFM, 8 GPM (Full Load), Direct Drive, Dual Capacity Scroll, 9" Diam x 7" W Blower Size, 1/2 HP (Blower Motor), Galvanized Steel (Cabinet), Copper (Coil Inner Tube), Steel (Coil Outer Tube), Vertical, 28" x 24" x 1" Filter Size, 2 Stage, 26,000 BTU/hr, 21.4 A (FLA), 24.4 A (MCA), 464.7 PSI (Working Water), 614.7 PSI (Working Refrigerant), 50-110 °F (Entering Air, Cooling), 40-80 °F (Entering Air, Heating), 30-120 °F (Entering Water), 60 Hz, 35 A Fuse Rating, Off White
- Features a high-efficiency, dual capacity Copeland UltraTechâ„¢ scroll compressor.
- Equipped with a variable-speed ECM blower motor for precise airflow control.
- Utilizes environmentally preferred R-410A refrigerant.
- Includes Aurora Base Controls for system management and diagnostics.
- Constructed with a heavy-gauge galvanized steel cabinet featuring a durable powder-coat finish.
- Designed for vertical upflow applications with a left return configuration.
- Achieves high energy efficiency ratings up to 24.0 EER (Ground Water, Full Load).
