| Additional Information | : | Uncrated Dimensions (HxWxD):: 49.9 x 17.5 x 21.8 |
| Airflow Capacity | : | 2 Nominal Tonnage (cfm/ton) |
| Airflow Configuration | : | Multi-positional 4-Way |
| Airflow Type | : | High Efficiency |
| BTUH(208V) | : | BAYEAAC04**1 - 9800, BAYEAAC05**1 - 12300, BAYEAAC08**1 - 19700, BAYEAAC10**1 - 24600, BAYEAAC10LG3 - 24600 |
| BTUH(240V) | : | BAYEAAC04**1 - 13100, BAYEAAC05**1 - 16400, BAYEAAC08**1 - 26200, BAYEAAC10**1 - 32800, BAYEAAC10LG3 - 32800 |
| BTUH | : | 24,000 |
| Blower Type | : | Vortica |
| Cabinet Size(W x D) | : | 17.5 x 21.8 |
| Coil Face Area (Sq-Ft) | : | 3.67 |
| Coil Rows | : | 3 |
| Coil Type | : | Plate Fin |
| CoilDesign | : | Plate Fin |
| Connection Type | : | Brazed |
| Convertability | : | Multi-Position 4-Way |
| CoolingCapacity | : | 24,000 BTU |
| Dimensions | : | 49-15/16 x 17-1/2 x 21-13/16 |
| Drain Connection Size (In) | : | 3/4 NPT |
| Drive Type | : | Direct - Variable |
| Duct Size (In) | : | 14.5 X 14.35 |
| ElecHertz | : | 60 |
| ElecPhases | : | 1 |
| ElecVolts | : | 200-230 |
| FPI | : | 14 |
| Fan Diameter (In) | : | 11 |
| Fan Motor FLA | : | 3 - 4.1 |
| Fan Type | : | Centrifugal |
| Filter Furnished | : | No |
| Filter Size (In) | : | 16 x 20 x 1 |
| Filter Type | : | Throwaway |
| FilterSize | : | 16 x 20 x 1 |
| Flow Control | : | EEV |
| Footprint Depth | : | 21.8 |
| Footprint Width | : | 17.5 |
| Full Load Amperage (FLA) | : | 3 - 4.1 |
| Heater (KW) 208V | : | BAYEAAC04**1 - 2.88, BAYEAAC05**1 - 3.60, BAYEAAC08**1 - 5.76, BAYEAAC10**1 - 7.20, BAYEAAC10LG3 - 7.20 |
| Heater (KW) 240V | : | BAYEAAC04**1 - 3.84, BAYEAAC05**1 - 4.80, BAYEAAC08**1 - 7.68, BAYEAAC10**1 - 9.60, BAYEAAC10LG3 - 9.60 |
| Heater Amps per Circuit(208V) | : | No Heater - 4.1 **, BAYEAAC04**1 - 13.8, BAYEAAC05**1 - 17.3, BAYEAAC08**1 - 27.7, BAYEAAC10**1 - 34.6, BAYEAAC10LG3 - 20.0 |
| Heater Amps per Circuit(240V) | : | No Heater - 4.1 **, BAYEAAC04**1 - 16.0, BAYEAAC05**1 - 20.0, BAYEAAC08**1 - 32.0, BAYEAAC10**1 - 40.0, BAYEAAC10LG3 - 23.1 |
| Line Size - Gas In | : | 3/4 |
| Line Size Gas | : | 3/4 |
| Line Size Liquid | : | 3/8 |
| MCA(208V) | : | No Heater - 5, BAYEAAC04**1 - 22, BAYEAAC05**1 - 27, BAYEAAC08**1 - 40, BAYEAAC10**1 - 48, BAYEAAC10LG3 - 30 |
| MCA(240V) | : | No Heater - 5, BAYEAAC04**1 - 25, BAYEAAC05**1 - 30, BAYEAAC08**1 - 45, BAYEAAC10**1 - 55, BAYEAAC10LG3 - 34 |
| MCA | : | 5 |
| MOCP(240V) | : | No Heater - 15, BAYEAAC04**1 - 25, BAYEAAC05**1 - 30, BAYEAAC08**1 - 45, BAYEAAC10**1 - 60, BAYEAAC10LG3 - 35 |
| MOP | : | 15 |
| Material | : | Double Wall Foamed and Formed |
| Specifications1 | : | Motor (RPM):: Variable ECM|Motor HP:: 1/2|Motor Speed:: Variable ECM|Motor Type:: Variable Speed|Nominal Capacity BTUs:: 24,000|Nominal Cooling Capacity BTU Rating:: 24,000|Number of Blower Speed:: Direct - Variable|Number of Fan Motors:: 1|Number of Phase:: 1|Power Supply:: 200-230V/1Phase/60Hz|Product Tier:: Premuim, Link Communication /24V |
| Specifications2 | : | Product Type:: Air Handler Unit|Refrigerant:: R-410A|Refrigerant Control:: EEV|Refrigerant Type:: R-410A|Return Opening Length:: 14.5|Return Opening Width:: 17.149|ReturnHght (In):: 14.5|ReturnWdth (In):: 17.149|Supply Opening Length:: 14.5|Supply Opening Width:: 14.35|SupplyHght (In):: 14.5|SupplyWdth (In):: 14.35|Tonnage:: 2|Tonnage(208V):: BAYEAAC04**1 - 0.8166,BAYEAAC05**1 - 1.025,BAYEAAC08**1 - 1.6416,BAYEAAC10**1 - 2.05,BAYEAAC10LG3 - 2.05|Tonnage(240V):: BAYEAAC04**1 - 1.0916,BAYEAAC05**1 - 1.3666,BAYEAAC08**1 - 2.1833,BAYEAAC10**1 - 2.7333,BAYEAAC10LG3 - 2.7333|Tube Size (In):: 0.375|Type:: Air Handler/Coil |
