| AFUE Rating % | : | 97 |
| Ampacity | : | 13.43 |
| Blower (Dia x W) (In) | : | 11 x 10 |
| Blower Drive | : | Direct |
| Blower FLA | : | 10 |
| Blower Fan Motor HP | : | 1 |
| Blower Fan Power | : | 120 V/1 Phase/60 Hz |
| Blower Fan RPM | : | Variable |
| Burner Type | : | Inshot |
| Capacity (BtuH) | : | Stage1 = 77050 (ICS); Stage2 = 116250 (ICS) |
| Combustion Fan Drive | : | Direct |
| Combustion Fan FLA | : | 0.77 |
| Combustion Fan Inducer Orifice | : | 1.19 |
| Combustion Fan Motor HP | : | 1/50 |
| Combustion Fan Power | : | 33/110 V/3Phase/60/180 Hz |
| Combustion Fan Speeds | : | Variable |
| Combustion Fan Type | : | Variable |
| Combustion Fan-RPM | : | 5000 |
| Configuration | : | Upflow, Horizontal |
| Crated Dimensions (H X W X D) | : | 35-1/2 x 26-1/2 x 30-7/8 in |
| Drill Size LP Gas (Qty - Drill Size) | : | 6 - 56 |
| Drill Size Nat Gas (Qty - Drill Size) | : | 6 - 45 |
| Energy Star Compliant | : | Yes |
| Filter Furnished | : | No |
| Filter Hi Vel. (No.-Size-Thk.) | : | 1 - 24 x 25 - 1 |
| Filter Type Recommended | : | High Velocity |
| Gas Valve Type | : | Redundant - 2-Stage |
| Heat Exchanger Gauge (Fired) | : | 20 |
| Heat Exchanger Type - Fired | : | 409 Stainless Steel |
| Heat Exchanger Type - Unfired | : | 29-4C Stainless Steel |
| Inlet Size (In) | : | 3 in Round |
| Input BTUH Stage 1 (BTU-HR) | : | 78000 |
| Input BTUH Stage 2 (BTU-HR) | : | 120,000 |
| Line Size - Suction (In) | : | 1/2 |
| MOCP | : | 15 |
| Model Number | : | S9V2 |
| Number of Blower Speed | : | Variable |
| Number of Blower Wheels Used | : | 1 |
| Number of Burners | : | 6 |
| Pilot Safety Device | : | SiNi Igniter |
| Power Supply | : | 120 V/1 Phase/60 Hz |
| Return Air Temp. (Min. - Max.) deg F | : | 45 - 80 |
| Temperature Rise (Min-Max) deg F | : | Stage1 = 35 to 65; Stage2 = 40 to 70 |
| Uncrated Dimensions (HxWxD) | : | 34 x 24-1/2 x 28-3/4 in |
| Vent Size | : | 3 in Round |
