| Body Length | : | 4.312 |
| Design Torque | : | 17.5 Oz-ft at 230V |
| Enclosure Type | : | TEAO |
| Flat Length (In) | : | 2.25 |
| Frame Size | : | 48 |
| Frequency Rating | : | 60 Hz |
| HP (Decimal) | : | 0.33 |
| HP (Fraction) | : | 1/3 |
| Insulation Class | : | F |
| Motor Length (IN) | : | 4.312 |
| Number of Phase | : | 1 |
| Number of Speeds | : | 1 |
| Rotation | : | CCW / LE |
| Shaft Diameter (In) | : | 0.5 |
| Shaft Length (In) | : | 2.75 |
| Speed (RPM) | : | 1,800 |
| Suggested Capacitor | : | 5.0 MFD/370V AC |
| Voltage (VAC) | : | 200 to 230 |
| Wire Length (in) | : | 36 |
