TITAN HD® PRCFD Series PRCFD255A Motor Dual Run Capacitor, MFD Rating: 25+5 uF, 370/440 VAC, Round, 2 in Dia, 2.91 in H
TITAN HD® PRCFD Series PRCFD255A Motor Dual Run Capacitor, MFD Rating: 25+5 uF, 370/440 VAC, Round, 2 in Dia, 2.91 in H
Manufacturer: DiversiTech Corporation
Brand: TITAN HD®
Part #: 388851
MPN: PRCFD255A
Customer Part #:
Min. Order Qty: 1
Login for Availability
| Average Life | : | 60000 hr |
| Case Material | : | Aluminum |
| Diameter | : | 2 in |
| Frequency Rating | : | 50/60 Hz |
| Height | : | 2.91 in |
| MFD Rating | : | 25+5 uF |
| Series | : | PRCFD Series |
| Shape | : | Round |
| Standard Tolerance | : | +/-5 % |
| Temperature Rating | : | -40 to 70 deg C |
| Terminal Type | : | Standard Blade |
| Voltage Rating | : | 370/440 VAC |
Packard has received the call to create a USA-made capacitor to provide contractors with confidence on the job. Our answer is Titan HD™. With a substantial 60,000 hours of operating life, it is just as hardworking as those who made them.
TITAN HD® Motor Dual Run Capacitor, PRCFD Series, 25+5 uF MFD Rating, 370/440 VAC, 50/60 Hz, Round Shape, Standard Blade Terminal, 60000 hr Average Life, +/-5 % Standard Tolerance, -40 to 70 deg C, Aluminum Case, 2 in Diameter, 2.91 in Height
- Eye catching packaging for retail environment
- Contains metalized polypropylene film technology for self-restoration in the event of a breakdown
- Sophisticated UL approved pressure sensitive interrupter to remove the capacitor from circuit at end of life
- Patented, environmentally friendly oil prevents corrosion and aids in optimum heat transfer
- Aluminum cans filled with soybean based oil
- Meets the rigorous EIA-456-A industry standard for performance and quality
- Made in USA
