Linesets, Inc DA06050 Copper Tubing Coil, 3/8" Outside Diameter, 600" Length, C12200 Copper, Seamless, Annealed Construction, Annealed Hardness, 787 PSI (@ 200°F) Working Pressure, 400 °F (Maximum, Working)
Linesets, Inc DA06050 Copper Tubing Coil, 3/8" Outside Diameter, 600" Length, C12200 Copper, Seamless, Annealed Construction, Annealed Hardness, 787 PSI (@ 200°F) Working Pressure, 400 °F (Maximum, Working)

Linesets, Inc DA06050 Copper Tubing Coil, 3/8" Outside Diameter, 600" Length, C12200 Copper, Seamless, Annealed Construction, Annealed Hardness, 787 PSI (@ 200°F) Working Pressure, 400 °F (Maximum, Working)

Linesets, Inc DA06050 Copper Tubing Coil, 3/8" Outside Diameter, 600" Length, C12200 Copper, Seamless, Annealed Construction, Annealed Hardness, 787 PSI (@ 200°F) Working Pressure, 400 °F (Maximum, Working)

Manufacturer: Mueller Industries
Brand: Streamline®
Part #: 386419
MPN: DA06050
Customer Part #:
Min. Order Qty: 1
Login for Availability
Login for Price
Diameter      :      3/8 in
Finish      :      Bright
For Use With      :      HVAC/R Systems, Mechanical Applications
Hardness      :      Annealed
Height      :      50 ft
Length      :      600 "
Material Construction      :      Seamless, Annealed
Material      :      C12200 Copper
Nominal Size      :      3/8 "
Outside Diameter      :      3/8 "
Resistance Properties      :      Oxidation Resistant (During Brazing)
Temperature Rating      :      400 °F (Maximum, Working)
Wall Thickness      :      0.032 "
Working Pressure      :      787 PSI (@ 200°F)

Streamline® Refrigeration Service Tube is of a consistent dead soft temper, bright, thoroughly dried/dehydrated and packed in shrink wrapping plus individual cartons for the highest level of protection.

Linesets, Inc Copper Tubing Coil, 3/8" Outside Diameter, 600" Length, C12200 Copper, Seamless, Annealed Construction, Annealed Hardness, 787 PSI (@ 200°F) Working Pressure, 400 °F (Maximum, Working), 0.032" Wall Thickness, Oxidation Resistant (During Brazing), For Use With HVAC/R Systems, Mechanical Applications, Bright Finish

  • Manufactured from high-quality C12200 grade copper to meet ASTM B280 standards.
  • Consistent dead soft temper allows for easy bending and forming during installation.
  • Thoroughly dried, dehydrated, and sealed to maintain system cleanliness.
  • Nitrogen charged to minimize internal oxidation during brazing operations.
  • UL Recognized with a maximum pressure rating of 700 PSI at 250°F.
  • Suitable for use in various HVAC/R and mechanical applications.
  • Made in the USA.
  • Data Sheet https://s3.amazonaws.com/open-secret-production-public/data-studio/marcone/documents/copper-tube-for-hvacr-applications-data-sheet-3689-5744.pdf
  • Catalog https://s3.amazonaws.com/open-secret-production-public/data-studio/marcone/documents/product-catalog-3689-5828.pdf
