Streamline CYCLEMASTER Multi Split A 18948 Ball Valve, 5/8" Nominal Size, Unibody Female, Male SAE Flare, Flare Port Type, Male x Female Flare, Refrigerant (CFC, HCFC, HFC, HFO, A2L) Media, 775 PSI, -40-300 °F
Streamline CYCLEMASTER Multi Split A 18948 Ball Valve, 5/8" Nominal Size, Unibody Female, Male SAE Flare, Flare Port Type, Male x Female Flare, Refrigerant (CFC, HCFC, HFC, HFO, A2L) Media, 775 PSI, -40-300 °F
| Body Material | : | Brass |
| Connection Type | : | Male x Female Flare |
| Dimensions | : | 5.98" L x 2.23" H x 1.16" W |
| Domestic/Import | : | Domestic |
| End Type | : | Unibody Female, Male SAE Flare |
| Flow Rate | : | 10 Cv |
| Inlet to Outlet Length | : | 5-49/50 " |
| Media | : | Refrigerant (CFC, HCFC, HFC, HFO, A2L) |
| Model | : | A 18948 |
| Nominal Size | : | 5/8 " |
| Number of Ports/Ways | : | 2 |
| Port Type | : | Flare |
| Pressure Rating | : | 775 PSI |
| Seal Material | : | MCM |
| Series | : | CYCLEMASTER Multi Split |
| Softgoods Material | : | MCM Seals / Dual O-Ring Seals |
| Temperature Rating | : | -40-300 °F |
This CYCLEMASTER refrigerant ball valve provides reliable flow control in various refrigeration and HVAC systems. It features 5/8" male and female flare connections, allowing for straightforward installation and removal during service.Designed with a durable unibody construction, this valve minimizes potential leak paths often found in multi-component valves. It operates effectively across a wide temperature range (-40°F to 300°F) and is rated for a maximum pressure of 775 PSI, making it suitable for demanding applications with CFC, HCFC, HFC, HFO, and A2L refrigerants.
Streamline Ball Valve, Model: CYCLEMASTER Multi Split, 5/8" Nominal Size, Unibody Female, Male SAE Flare, Flare Port Type, Male x Female Flare, Refrigerant (CFC, HCFC, HFC, HFO, A2L) Media, 775 PSI, -40-300 °F, 2-Way, Brass, 10 Cv, MCM, 5.98" L x 2.23" H x 1.16" W Dimensions, 5-49/50" Inlet To Outlet Length, Domestic
- Features durable unibody construction to enhance reliability and minimize potential leak points.
- Equipped with 5/8" male and female flare connections for easy installation and repeated servicing.
- Rated for a maximum operating pressure of 775 PSI.
- Suitable for a wide operating temperature range from -40°F to 300°F.
- Compatible with common refrigerants including CFC, HCFC, HFC, HFO, and A2L.
- Includes an access port to facilitate system diagnostics and service.
- UL/cUL Listed, meeting relevant safety standards.
