Streamline CYCLEMASTER Multi Split A 18947 Ball Valve, 1/2" Nominal Size, Unibody Female, Male SAE Flare, Flare Port Type, Male x Female Flare, CFC, HCFC, HFC, HFO, Oils Media, 789.7 PSI, -40-300 °F
Streamline CYCLEMASTER Multi Split A 18947 Ball Valve, 1/2" Nominal Size, Unibody Female, Male SAE Flare, Flare Port Type, Male x Female Flare, CFC, HCFC, HFC, HFO, Oils Media, 789.7 PSI, -40-300 °F
| Body Material | : | Brass |
| Connection Type | : | Male x Female Flare |
| Dimensions | : | 5.98" L x 2.23" H x 1.16" W |
| Domestic/Import | : | Domestic |
| End Type | : | Unibody Female, Male SAE Flare |
| Flow Rate | : | 5 Cv |
| Inlet to Outlet Length | : | 5-49/50 " |
| Media | : | CFC, HCFC, HFC, HFO, Oils |
| Model | : | A 18947 |
| Nominal Size | : | 1/2 " |
| Number of Ports/Ways | : | 2 |
| Port Type | : | Flare |
| Pressure Rating | : | 789.7 PSI |
| Seal Material | : | MCM |
| Series | : | CYCLEMASTER Multi Split |
| Softgoods Material | : | MCM Seals / Dual O-Ring Seals |
| Temperature Rating | : | -40-300 °F |
Streamline CYCLEMASTER® multi split ball valves feature full port construction, environmentally friendly, chromium-plated balls for reduced wear and extended seal life, and our exclusive MCMTM seals for industry-leading longevity and low leak rates. The insulation covers eliminate time and hassle associated with cutting insulation in the field.
Streamline Ball Valve, Model: CYCLEMASTER Multi Split, 1/2" Nominal Size, Unibody Female, Male SAE Flare, Flare Port Type, Male x Female Flare, CFC, HCFC, HFC, HFO, Oils Media, 789.7 PSI, -40-300 °F, 2-Way, Brass, 5 Cv, MCM, 5.98" L x 2.23" H x 1.16" W Dimensions, 5-49/50" Inlet To Outlet Length, Domestic
- Engineered for multi-split A/C and heat pump units.
- Features full port construction to match line size ID for optimal flow.
- Rupture-proof encapsulated stem and exclusive MCMâ„¢ seals enhance durability and reduce leak potential.
- Chromium-plated ball provides reduced wear and longer seal life.
- Compatible with CFC, HCFC, HFC, and HFO refrigerants and associated oils.
- Includes an access port for service convenience.
- UL/cUL listed and conforms to Pressure Equipment Directive 2014/68/EU.
