RunTru A951X080CU5SAB 5T 96 AFUE Condensing Single Stage Gas Furnance
RunTru A951X080CU5SAB 5T 96 AFUE Condensing Single Stage Gas Furnance
Manufacturer: Trane International Inc
Brand: RUNTRU® By Trane
Part #: 384899
MPN: A951X080CU5SAB
Customer Part #:
Min. Order Qty: 1
Login for Availability
Login for Price
| AFUE Rating | : | 96 % |
| Additional Information | : | 409 Stainless Steel Exchanger Material |
| Amperage Rating | : | 14.1 A |
| Blower Size | : | 11 in Dia x 10 in W in |
| CFM Rating | : | 400 cfm |
| Cabinet Dimensions | : | 34 in H x 21 in W x 28-3/4 in D in |
| Configuration | : | Upflow, Horizontal |
| Connection Size | : | 1/2 in |
| Domestic/Import | : | Domestic |
| Energy Star Compliant | : | Yes |
| Frequency Rating | : | 60 Hz |
| Fuel Type | : | Natural Gas |
| Fuse Rating | : | 15 A |
| HP Rating | : | 1 hp |
| Ignition Type | : | Silicon Nitride |
| Input BTU Rating | : | 80,000 Btu/hr |
| Material | : | Steel |
| Model Number | : | A951 |
| Motor Type | : | ECM |
| Number of Burners | : | 4 |
| Number of Speeds | : | 9 |
| Number of Stages | : | Single |
| Output BTU Rating | : | 77,000 Btu/hr |
| Pressure Rating | : | 0.5 in-WG |
| Rotational Speed | : | 1075 rpm |
| Series | : | A951X |
| Temperature Rise | : | 40 to 70 deg F |
| Tonnage | : | 5.0 Ton |
| Transformer Rating | : | 24/120 VAC |
| Vent, Ducted or Ductless | : | Vent |
| Voltage Rating | : | 115/120 V |
| Width | : | 21.0 in |
RunTru - A951X080CU5SAB, 5T , 96% AFUE, 80,000 BTU, 120V, ECM Fan Motor, Upflow Condensing Single Stage Gas Furnance
- Adjustable blower off delay for heating and cooling
- Heavy gauge reinforced wrap-around steel cabinet
- 3 Way poise Upflow furnace model (Upflow, Horzontal Left, Horizontal Right
- Manual reset flame roll out switches
- Multiple venting options - Every model, every size will offer two venting options
- Integrated Furnace Control board with digital configuration, status, and fault codes
- Constant Torque (ECM) Motor
