| Additional Information | : | CTM Motor Type, Orifice Flow Control |
| BTU Rating | : | 24,000 Btu/hr |
| Blower type | : | Constant Torque ECM |
| CFM Rating | : | 800 cfm |
| Configuration | : | Multi-Position |
| Dimensions | : | 45.02 in H x 18.5 in W x 21.13 in D |
| Efficiency Rating | : | 14 |
| Energy Star Compliant | : | N |
| Finish | : | Galvanized |
| Flow Control | : | TXV |
| Frequency Rating | : | 60 Hz |
| Material | : | Steel |
| Motor Type | : | ECM |
| Number of Stages | : | Single |
| Phase | : | 1 ph |
| Refrigerant Control | : | TXV |
| Refrigerant Type | : | R-410A |
| Series | : | A4AH4 |
| Tonnage | : | 2.0 Ton |
| Voltage Rating | : | 208/230 V |
RunTru A4AH4E24A1B60 24,000 BTU, 2T 14.3 SEER2, 208/230V, ECM Fan Motor, 4-Way Multi-Position, Single Stage Air Handler
- Unpainted galvanized metal cabinet with captured foil face insulation
- All Aluminum Coil with Enhanced Patented Coil Fin
- Factory installed orifice with mechanical connections on both sides
- Approved for manufactured/mobile home use
- Multi-Position Upflow / Downflow,* Horizontal Left /Right
- Factory installed R-410A Thermal Expansion Valve with mechanical connections on both sides
