resideo Deluxe Series DP1030A5014/U Definite Purpose Contactor, 24 V Coil, 48 A, SPST, 1-Pole
resideo Deluxe Series DP1030A5014/U Definite Purpose Contactor, 24 V Coil, 48 A, SPST, 1-Pole
Manufacturer: Resideo Technologies Inc
Brand: resideo
Part #: 386539
MPN: DP1030A5014/U
Customer Part #:
Min. Order Qty: 1
Login for Availability
Login for Price
| Additional Information | : | 1/4 in Quick-Connect Size |
| Amperage Rating | : | 48 A |
| Coil Voltage | : | 24 V |
| Contact Configuration | : | SPST |
| Number of Poles | : | 1 |
| Overall Depth | : | 3.31 in |
| Overall Height | : | 2.2 in |
| Overall Width | : | 2-1/2 in |
| Series | : | Deluxe Series |
resideo Definite Purpose Contactor, Series: Deluxe Series, 24 V Coil, 48 A, 1-Pole, SPST Contact Configuration, 2-1/2 in Overall Width, 3.31 in Overall Depth, 2.2 in Overall Height, Additional Information: 1/4 in Quick-Connect Size
- Meets ARI-780 standard at started ratings (500000 cycle mechanical life, 200000 cycle electrical life and 10000 cycle recycle life), the most demanding ARI requirement
- Silver cadmium oxide contacts provide long life under demanding-duty cycles
- Low profile design allows for more wiring room
- Multiple mounting holes and slots for convenient, interchangeable-mounting with most competitive devices
- Provide switching for starting induction motor
