resideo AT150F1030/U General Purpose Transformer, 208/277/480 V Primary, 24 V Secondary, 50 VA
resideo AT150F1030/U General Purpose Transformer, 208/277/480 V Primary, 24 V Secondary, 50 VA
Manufacturer: Resideo Technologies Inc
Brand: resideo
Part #: 385546
MPN: AT150F1030/U
Customer Part #:
Min. Order Qty: 1
Login for Availability
Login for Price
| Class | : | 2 |
| Overall Depth | : | 3-5/8 in |
| Overall Height | : | 3-3/16 in |
| Overall Width | : | 2-3/16 in |
| Power Rating | : | 50 VA |
| Primary Voltage | : | 208/277/480 V |
| Secondary Voltage | : | 24 V |
| Series | : | AT150F Series |
resideo offers NEMA standard DC20-1992 and general purpose transformers. These transformers are available with single or multiple input voltages and with foot, conduit and plate-mounting options. Transformers with circuit breakers that can be manually reset by pressing a button are also available. resideo also designs transformers for specific environmental requirements and with specialized termination options.
resideo General Purpose Transformer, Series: AT150F Series, 208/277/480 V Primary, 24 V Secondary Voltage, 50 VA, Class: 2, 2-3/16 in Overall Width, 3-5/8 in Overall Depth, 3-3/16 in Overall Height
- Color-coded lead wires for primary connections and screw terminals for secondary connections
- Includes fixed 1/4 in male quick-connects (AT150A models only) or color-coded lead wires for primary and secondary connections
