RectorSeal All-Access AA3 Drain Pan Float Switch, Clip-On (Drain Pan Edge), 6 Ft 18 AWG Wired / Lead Wires (Electrical), 7" L x 8-1/2" H x 2" W Size, PVC, White
RectorSeal All-Access AA3 Drain Pan Float Switch, Clip-On (Drain Pan Edge), 6 Ft 18 AWG Wired / Lead Wires (Electrical), 7" L x 8-1/2" H x 2" W Size, PVC, White
Manufacturer: CSW Industrials Inc
Brand: RectorSeal®
Part #: 384342
MPN: 83413
Customer Part #:
Min. Order Qty: 1
Login for Availability
Login for Price
| Color | : | White |
| Connection Type | : | Clip-On (Drain Pan Edge), 6 ft 18 AWG Wired / Lead Wires (Electrical) |
| Material | : | PVC |
| Model | : | AA3 |
| Series | : | All-Access |
| Size | : | 7" L x 8-1/2" H x 2" W |
| Suitable For Use With | : | Primary or Auxiliary Drain Pans; Condensate Drain Lines; A/C Condensate Drains |
All-Access AA3 specially designed plastic mounting bracket clips firmly over the edge of most drain pans and the slim-profile AA3 can be installed on primary or auxiliary drain pans. The patented magnetic reed switch allows it to be installed off-center and still function correctly.
RectorSeal Drain Pan Float Switch, Model: All-Access, Clip-On (Drain Pan Edge), 6 Ft 18 AWG Wired / Lead Wires (Electrical), 7" L x 8-1/2" H x 2" W Size, PVC, White
- Detects clogged condensate drains and automatically shuts off the system to prevent water damage.
- Installs easily on primary or auxiliary drain pans using the sturdy plastic clip and accessible thumbscrew.
- Patented magnetic reed switch allows for off-center installation while maintaining proper function.
- Features adjustable float switch sensitivity for customized setup.
- Potted, electrically water-sealed switch design enhances durability in damp environments.
- Includes 6 ft, 18 AWG lead wires for connection to 24 VAC Class 2 circuits.
- Tested to UL508 standards for reliable performance.
