Mitsubishi Electric MSZ-GS MUZ-GS30NA2-U1 Single-Zone Heat Pump Outdoor Unit, 208/230 V, 30600 Btu/hr Cooling
Mitsubishi Electric MSZ-GS MUZ-GS30NA2-U1 Single-Zone Heat Pump Outdoor Unit, 208/230 V, 30600 Btu/hr Cooling
Manufacturer: Mitsubishi Electric Trane HVAC US LLC
Brand: Mitsubishi Electric Trane®
Part #: 388288
MPN: MUZ-GS30NA2-U1
Customer Part #:
Min. Order Qty: 1
Login for Availability
| Additional Information | : | 450 rpm Low, 810 rpm Medium, 900 rpm High Cooling, 560 rpm Low, 800 rpm Medium, 800 rpm High Heating |
| Color | : | Munsell |
| Connection Type | : | Flared |
| Cooling BTU Rating | : | 30600 Btu/hr |
| Cooling CFM Rating | : | 1024 to 2191 cfm |
| Cooling Sound Level | : | 55 dBA |
| EER Rating | : | 9.2 |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 25 A |
| HSPF Rating | : | 8.9 |
| Heating BTU Rating | : | 20000 Btu/hr, 32600 Btu/hr |
| Heating CFM Rating | : | 1328 to 1950 cfm |
| Heating Sound Level | : | 57 dBA |
| Liquid Line Size | : | 1/4 in |
| Model | : | MSZ-GS |
| Mounting Type | : | Wall |
| Overall Height | : | 13 in |
| Overall Length | : | 34-5/8 in |
| Overall Width | : | 33-1/16 in |
| Phase | : | 1 ph |
| Power Rating | : | 3340 W |
| Refrigerant Type | : | R-410A |
| SEER Rating | : | 19.1 |
| Suction Line Size | : | 5/8 in |
| Voltage Rating | : | 208/230 V |
Mitsubishi Electric Single-Zone Heat Pump Outdoor Unit, Model: MSZ-GS, 208/230 V, 3340 W Power, 60 Hz Frequency, 1 ph, Heating BTU Rating: 20000 Btu/hr, 32600 Btu/hr, Cooling BTU Rating: 30600 Btu/hr, Heating CFM Rating: 1328 to 1950 cfm, Cooling CFM Rating: 1024 to 2191 cfm, 9.2 EER, 19.1 SEER, 8.9 HSPF, Flared Connection, R-410A Refrigerant, 1/4 in Liquid Line, 5/8 in Suction Line, 25 A Fuse, Heating Sound Level: 57 dBA, Cooling Sound Level: 55 dBA, Wall Mounting, Munsell, 34-5/8 in Overall Length, 33-1/16 in Overall Width, 13 in Overall Height, Additional Information: 450 rpm Low, 810 rpm Medium, 900 rpm High Cooling, 560 rpm Low, 800 rpm Medium, 800 rpm High Heating
- Single-zone inverter driven heat pump, blue fin-coated applied to heat exchanger for increased protection and longer life
- Inverter driven compressor and LEV provide high efficiency and comfort while using only the energy needed to maintain maximum performance
- Blue Fin anti-corrosion treatment applied to the outdoor unit heat exchanger for increased coil protection and longer life
- Rated for 2000 hr spraying time per ASTM B117 Standard
