Mitsubishi Electric Trane® MSZ-WX09NL Indoor Split-Type Air Conditioner Unit, 208/230 V, 1 A, 9000 Btu/hr BTU
Mitsubishi Electric Trane® MSZ-WX09NL Indoor Split-Type Air Conditioner Unit, 208/230 V, 1 A, 9000 Btu/hr BTU
Manufacturer: Mitsubishi Electric Trane HVAC US LLC
Brand: Mitsubishi Electric Trane®
Part #: 388225
MPN: MSZ-WX09NL
Customer Part #:
Min. Order Qty: 1
Login for Availability
| Amperage Rating | : | 1 A |
| BTU Rating | : | 9000 Btu/hr |
| CFM Rating | : | 381/301/210/147 cfm Cooling, 391/321/224/147 cfm Heating |
| Color | : | White |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 15 A |
| Mounting Type | : | Wall |
| Overall Height | : | 11-1/32 in |
| Overall Length | : | 33 in |
| Overall Width | : | 8-31/32 in |
| Phase | : | 1 ph |
| Series | : | MUZ-WX-NL Series |
| Sound Level | : | 43 dBA |
| Temperature Rating | : | 66 to 90 deg F |
| Voltage Rating | : | 208/230 V |
Mitsubishi Electric Trane® Indoor Split-Type Air Conditioner Unit, Series: MUZ-WX-NL, 208/230 V, 1 A, 60 Hz, 1 ph, 9000 Btu/hr, 381/301/210/147 cfm Cooling, 391/321/224/147 cfm Heating, 15 A Fuse Rating, 43 dBA Sound Level, Wall Mounting, White, 66 to 90 deg F, 33 in Overall Length, 8-31/32 in Overall Width, 11-1/32 in Overall Height
- 12-hour timer
- Auto restart
- Econo Cool: Econo Cool temporarily and automatically adjusts the airflow based on heat exchanger temperature - The set temperature is increased slightly, which saves energy, while maintaining comfort
- Electrostatic Enzyme Filer: Charged with static electricity, the Electrostatic filter is designed to attract and filter charged particles which can include airborne non-living particulates
- Four fan speed options: Low, Medium, high, Super-high
- Multiple control options including: Back-lit screen hand-held Remote Controller (provided with unit), comfort app, third-party interfaces and both wired and wireless controllers
- Nano Platinum Filter: This filter has a large capture area and incorporates nanometer-sized platinum-ceramic particles and is designed to reduce the presence of certain nonliving particles, while deodorizing the circulating air
- Smart Dry Mode: Improves humidity control with minimal over-cooling of the space
