Humid-A-Mist HUMID-A-MIST HUM-100-NS Humidifier, 1.4 GPD-14.4 GPD, ≤3,000 Sq. Ft. Coverage Area, 120 VAC (Fan Switch/Main), 24 VAC (Control), 1 Phase, 10 A (FLA, 120V AC); 0.425 A (24V AC), 15 A (Internal Bus Fuse) Fuse Rating, Solid State Control, Humidistat
Humid-A-Mist HUMID-A-MIST HUM-100-NS Humidifier, 1.4 GPD-14.4 GPD, ≤3,000 Sq. Ft. Coverage Area, 120 VAC (Fan Switch/Main), 24 VAC (Control), 1 Phase, 10 A (FLA, 120V AC); 0.425 A (24V AC), 15 A (Internal Bus Fuse) Fuse Rating, Solid State Control, Humidistat
| Amperage Rating | : | 10 A (FLA, 120V AC); 0.425 A (24V AC) |
| Capacity | : | 1.4 GPD-14.4 GPD |
| Circuit Protection | : | 15 A (Internal bus fuse) |
| Connection Size | : | 1/8" MPT x 1/4" comp, 1/4" MPT x 1/4" comp |
| Connection Type | : | MPT, Compression, Saddle Valve (Water Supply) |
| Control Type | : | Solid State Control, Humidistat |
| Coverage Area | : | 3,000 sq. ft. |
| Dimensions | : | 4-1/4" H x 5-1/2" W x 1-1/2" D |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 15 A (Internal Bus Fuse) |
| Humidity Rating | : | 1.4 GPD to 14.4 GPD (Adjustable based on timer settings) |
| Material | : | Brass/Stainless Steel (Nozzle), Epoxy (Coil), Brass (Body) |
| Mounting Type | : | Plenum Mount |
| Number of Speeds | : | 1 |
| Phase | : | 1 |
| Plenum Opening | : | 5/8" (Hole) |
| Series | : | HUMID-A-MIST |
| Voltage Rating | : | 120 VAC (Fan Switch/Main), 24 VAC (Control) |
| Water Supply | : | Cold Water Supply, 1/4" Tubing, Saddle Valve |
| Water Usage Rate | : | 1.4-14.4 GPD |
HUMID-A-MIST is a solid state humidification system that is incorporated into a forced air heating unit. Designed to maintain a broad range of humidity levels in residential or commercial spaces up to 3,000 sq. ft., it utilizes a bypass pulse board, misting nozzle, water solenoid valve, and a water filter cartridge. The pulse board pulses a mist of water at adjustable time intervals (providing 1.4 to 14.4 GPD) to accommodate various dwelling sizes and CFM requirements.This humidifier features multiple operating modes, including Unison, Bypass, and Standby, controlled by a solid-state bypass pulse board and gain switch for flexible humidity management. It operates efficiently using only cold water with no waste, minimal energy consumption (about 1/3 of a 40W bulb), requires no drain line, prevents standing water, and includes a 5-micron water filter for cleaner mist.
Humid-A-Mist Humidifier, Model: HUMID-A-MIST, 1.4 GPD-14.4 GPD, ≤3,000 Sq. Ft. Coverage Area, 120 VAC (Fan Switch/Main), 24 VAC (Control), 1 Phase, 10 A (FLA, 120V AC); 0.425 A (24V AC), 15 A (Internal Bus Fuse) Fuse Rating, Solid State Control, Humidistat, Plenum Mount, MPT, Compression, Saddle Valve (Water Supply), 1/8" MPT x 1/4" Comp, 1/4" MPT x 1/4" Comp Connection Size, Cold Water Supply, 1/4" Tubing, Saddle Valve, 5/8" (Hole) Plenum Opening, 4-1/4" H x 5-1/2" W x 1-1/2" D, 1-Speed, 60 Hz, Brass/Stainless Steel (Nozzle), Epoxy (Coil), Brass (Body)
- Solid-state system integrates with forced air heating for automated humidity control.
- Adjustable misting pulse provides 1.4 to 14.4 GPD output for spaces up to 3,000 sq. ft.
- Operates in multiple modes (Unison, Bypass, Standby) with or without a heating call.
- Conserves water by using 100% of the cold water supply; no drain required.
- Energy-efficient operation uses significantly less power than typical humidifiers.
- Includes a 5-micron water filter; installs via a 5/8" plenum opening.
- Features internal 15A fuse protection and a 2-year manufacturer warranty.
