Resideo Genesis 32145012 Shielded Control Cable, 2 Conductors, 18 AWG, Plenum PVC Jacket Material, Aluminum Foil/Mylar, Drain Wire, 300 V (Max), -4-167 °F, Twisted Pair
Resideo Genesis 32145012 Shielded Control Cable, 2 Conductors, 18 AWG, Plenum PVC Jacket Material, Aluminum Foil/Mylar, Drain Wire, 300 V (Max), -4-167 °F, Twisted Pair
| Capacitance | : | 59.3 pF/ft (nom.) |
| Color | : | Natural |
| Conductor Material | : | Bare Copper |
| Conductor Size | : | 18 AWG |
| Conductor Type | : | Twisted Pair |
| Impedance | : | 31 Ohms |
| Insulation Color | : | Black, Red |
| Insulation Material | : | Plenum PVC |
| Insulation Thickness | : | 0.007 " |
| Jacket Color | : | Natural |
| Jacket Material | : | Plenum PVC |
| Jacket Thickness | : | 0.015 " |
| Lay Length | : | 2-1/4 " |
| Length | : | 6,000 " |
| Material Standard | : | CMP, CL3P, FPLP, FT6, NFPA 262, CSA C22.2 No. 2556, ETL Listed, RoHS Compliant |
| Number of Conductors | : | 2 |
| Outside Diameter | : | 0.156 " |
| Package Type | : | Reel |
| Resistance | : | 6.66 Ohms (Per 1000 Ft @ 20°C, DC) |
| Series | : | Genesis |
| Shielding Type | : | Aluminum Foil/Mylar, Drain Wire |
| Solid/Stranded | : | Stranded |
| Strands | : | 19 |
| Temperature Rating | : | -4-167 °F |
| Thickness | : | 0.156 " |
This Genesis 18/2 shielded control cable provides a reliable connection for various low-voltage applications, including security systems, building controls, audio, and instrumentation. It features two stranded 18 AWG bare copper conductors, twisted for optimal signal integrity.The cable is plenum-rated (CMP, CL3P, FPLP, FT6) for safe installation in air handling spaces and includes an overall aluminum foil/Mylar shield with a tinned-copper drain wire to minimize electrical noise and interference. It utilizes low-smoke PVC insulation and a natural-colored plenum PVC jacket, rated for 300V and temperatures from -20°C to 75°C (-4°F to 167°F).
Resideo Shielded Control Cable, Model: Genesis, 2 Conductors, 18 AWG, Plenum PVC Jacket Material, Aluminum Foil/Mylar, Drain Wire, 300 V (Max), -4-167 °F, Twisted Pair, Stranded, 6,000" Length, CMP, CL3P, FPLP, FT6, NFPA 262, CSA C22.2 No. 2556, ETL Listed, Rohs Compliant, Plenum PVC, Natural, Black, Red, 0.015" (Nominal) Jacket Thickness, 0.007" (Nominal) Insulation Thickness, 0.156" (Nominal) Outside Diameter, 59.3 Pf/Ft (Nom.), 31 Ohms (Nominal), 19 Strands, 2-1/4" (Nominal) Lay Length, Bare Copper, 6.66 Ohms (Per 1000 Ft @ 20°C, DC), Reel
- Features two 18 AWG stranded (19 strand) bare copper conductors.
- Overall aluminum foil/Mylar shield with a tinned-copper drain wire minimizes electrical interference.
- Plenum-rated (CMP, CL3P, FPLP, FT6) with low-smoke PVC insulation and jacket for use in air handling spaces.
- Rated for 300V maximum and temperatures from -20°C to 75°C (-4°F to 167°F).
- Supplied in a 500 ft reel for convenient storage and installation.
- Includes a rip cord for efficient jacket stripping.
- ETL Listed and RoHS compliant.
