General Electric RealMAX Choice GG40T08BXR Tall Natural Gas Water Heater, 40 Gallons Capacity, 40,000 BTU/hr, Natural Gas, 83 GPH First Hour Delivery, 41.6 GPH (At 90°F Rise) Recovery Rate, No Energy Star Compliant, Atmospheric Vent Type
General Electric RealMAX Choice GG40T08BXR Tall Natural Gas Water Heater, 40 Gallons Capacity, 40,000 BTU/hr, Natural Gas, 83 GPH First Hour Delivery, 41.6 GPH (At 90°F Rise) Recovery Rate, No Energy Star Compliant, Atmospheric Vent Type
| Additional Information | : | Magnesium Anode Rod, High Bin Testing, LED Indicator Controls, Gas Valve Self Powered, 0.64 UEF, 3/4 x 3/4 in Connection |
| Altitude | : | 10,100 ' |
| BTU Rating | : | 40,000 BTU/hr |
| Capacity | : | 40 gallons |
| Color | : | Gray |
| Connection Type | : | 3/4" MNPT (Water Inlet/Outlet), 1/2" (Gas Connection) |
| Dimensions | : | 61-7/8" H x 20" W x 20" D |
| Domestic/Import | : | Domestic |
| Efficiency | : | 64% (UEF), 78% (Recovery Efficiency) |
| Energy Factor | : | 0.64 UEF |
| Energy Star Compliant | : | No |
| First Hour Delivery | : | 83 GPH |
| Fuel Type | : | Natural Gas |
| Ignition System | : | Standing Pilot |
| Ignition Type | : | Standing Pilot |
| Lead-Free/Contains Lead | : | Lead-Free |
| Material | : | Steel (Tank), Magnesium (Anode Rod) |
| Model | : | GG40T08BXR |
| Mounting Type | : | Floor Mount |
| Recovery Efficiency | : | 78 % |
| Recovery Rate | : | 41.6 GPH (At 90°F Rise) |
| Series | : | RealMAX Choice |
| Temperature Rating | : | 45-160 °F (Adjustable Setting) |
| Vent Diameter | : | 3 " |
| Vent Size | : | 3 " |
| Vent Type | : | Atmospheric |
This RealMAX Choice water heater provides a true 40 gallons of hot water capacity, suitable for households of 2 to 4 people. Its 40,000 BTU natural gas burner delivers rapid recovery and up to 83 gallons of hot water in the first hour (FHR). The tall, atmospheric vent design uses standard water and gas connections for straightforward replacement installations. Key features include the SmartShieldâ„¢ Safety System for monitoring ambient air temperatures and an LED indicator for gas system status. The unit is built for durability with a corrosion-resistant anode rod and a rust-proof drain valve, backed by an 8-year limited tank and parts warranty.
General Electric Tall Natural Gas Water Heater, Model: RealMAX Choice, 40 Gallons Capacity, 40,000 BTU/hr, Natural Gas, 83 GPH First Hour Delivery, 41.6 GPH (At 90°F Rise) Recovery Rate, No Energy Star Compliant, Atmospheric Vent Type, 3" Vent Size, 3/4" MNPT (Water Inlet/Outlet), 1/2" (Gas Connection), 61-7/8" H x 20" W x 20" D Dimensions, Floor Mount, 45-160 °F (Adjustable Setting), Standing Pilot, Steel (Tank), Magnesium (Anode Rod), 10,100' Altitude, Domestic, Lead-Free, Gray, 64% (UEF), 78% (Recovery Efficiency)
- Holds a true 40 gallons of water capacity for reliable hot water supply.
- Provides up to 83 gallons of hot water in the first hour (FHR) with a 40,000 BTU burner.
- Features the SmartShieldâ„¢ Safety System, which monitors ambient air and provides automatic shutdown protection.
- Includes a self-diagnostic system with an LED indicator for monitoring gas system status.
- Equipped with a durable anode rod for enhanced corrosion protection and extended tank life.
- Designed for easy replacement installation using standard 3/4" NPT water and 1/2" gas connections.
- Covered by an 8-year limited tank and parts warranty.
