DiversiTech PMR610 Manual High Pressure Control, 610 PSI (Open) Set Points, Manual, High Pressure Control, SPST (Open On Rise), SAE Female Flare With Valve Core Depressor, 1/4" Connection Size, 208-240 VAC
DiversiTech PMR610 Manual High Pressure Control, 610 PSI (Open) Set Points, Manual, High Pressure Control, SPST (Open On Rise), SAE Female Flare With Valve Core Depressor, 1/4" Connection Size, 208-240 VAC
| Accuracy | : | ± 15 PSI |
| Amperage Rating | : | 2.9 A (RLA, 208-240 VAC); 5.8 A (RLA, 110-120 VAC); 5 A (RLA, 48 VDC/VAC); 10 A (RLA, 12-28 VDC/VAC) |
| Close Pressure | : | Manual |
| Connection Size | : | 1/4 " |
| Connection Type | : | SAE Female Flare With Valve Core Depressor |
| Lead Length | : | 18 " |
| Maximum Pressure | : | 5,000 PSI (Burst) |
| Mounting Type | : | Direct Mount |
| Open Pressure | : | 610 PSI |
| Pressure Rating | : | 0-650 PSI (Working) |
| Rated Life Cycle | : | 100,000 cycles |
| Reset Type | : | Manual Reset |
| Set Points | : | 610 PSI (Open) |
| Suitable For Use With | : | Refrigeration Systems, Air Conditioning Systems, Heat Pump Systems (Including R410A) |
| Switch Type | : | High Pressure Control |
| Switching Action | : | SPST (Open On Rise) |
| Temperature Rating | : | 20-176°F (Ambient) |
| Voltage Rating | : | 208-240 VAC |
This manual reset high-pressure control switch features SPST switching action, opening the circuit when pressure rises to 610 PSI (± 15 PSI). It includes 18-inch wire leads and a 1/4-inch SAE female flare connection with a valve core depressor for direct mounting.Designed for durability, this switch operates within a 0-650 PSI working pressure range and is compatible with HFC, HCFC, and CFC refrigerants. It is suitable for various refrigeration, air conditioning, and heat pump systems, including those using R410A.
DiversiTech Manual High Pressure Control, 610 PSI (Open) Set Points, Manual, High Pressure Control, SPST (Open On Rise), SAE Female Flare With Valve Core Depressor, 1/4" Connection Size, 208-240 VAC, 2.9 A (RLA, 208-240 VAC); 5.8 A (RLA, 110-120 VAC); 5 A (RLA, 48 VDC/VAC); 10 A (RLA, 12-28 VDC/VAC), 0-650 PSI (Working), 5,000 PSI (Burst), 20-176°F (Ambient), Manual Reset, ± 15 PSI Accuracy, 100,000 Cycles (Average At RLA), Direct Mount, 18" Lead Length
- Provides high-pressure protection with manual reset functionality.
- SPST switch opens circuit on pressure rise at 610 PSI (± 15 PSI tolerance).
- Includes 18-inch, UL1015 18 AWG wire leads for installation.
- Features a standard 1/4" SAE female flare connection with valve core depressor.
- Suitable for refrigeration, air conditioning, and heat pump systems, including R410A applications.
- Rated for 100,000 cycles at RLA for long service life.
- UL Certified.
