Bosch 7-738-005-074 Circulator Pump, 3 Speeds, 0-33 GPM Flow Rate, 145 PSI (Max System), 36-230 °F (Liquid) Temperature Rating, Flange Mount, 230 V, 1 Phase
Bosch 7-738-005-074 Circulator Pump, 3 Speeds, 0-33 GPM Flow Rate, 145 PSI (Max System), 36-230 °F (Liquid) Temperature Rating, Flange Mount, 230 V, 1 Phase
| Amperage Rating | : | 0.9 A |
| Flow Rate | : | 0-33 GPM |
| Frequency Rating | : | 60 Hz |
| Model | : | 7-738-005-074 |
| Mounting Type | : | Flange Mount |
| Number of Speeds | : | 3 |
| Phase | : | 1 |
| Power Rating | : | 196 W |
| Pressure Rating | : | 145 PSI (Max System) |
| Specifications | : | cULus Listed, Classified UL, ANSI / NSF 61 |
| Suitable For Use With | : | Select Bosch/Florida Heat Pump Models; Geothermal Flow Centers, Ground-Source / Water-Source Heat Pumps, Hot & Chilled Water Systems |
| Temperature Rating | : | 36-230 °F (Liquid) |
| Voltage Rating | : | 230 V |
This pump serves as a replacement circulator, specifically designed for use with compatible Bosch/FHP heat pump models. It features three distinct speed settings for operational flexibility and operates on a 230V power supply.Engineered for reliability, this model is suitable for various applications including geothermal flow centers, ground-source and water-source heat pumps, and standard hot or chilled water circulation systems. It is designed without a volute.
Bosch Circulator Pump, 3 Speeds, 0-33 GPM Flow Rate, 145 PSI (Max System), 36-230 °F (Liquid) Temperature Rating, Flange Mount, 230 V, 1 Phase, 0.9 A, 196 W, 60 Hz, Culus Listed, Classified UL, ANSI / NSF 61
- Features three selectable speed settings for versatile operation.
- Delivers a flow rate up to 33 GPM.
- Operates on a 230V, single-phase power supply.
- Handles liquid temperatures ranging from 36°F to 230°F.
- Rated for a maximum system pressure of 145 PSI.
- Compatible with select Bosch/Florida Heat Pump models and various geothermal or hydronic systems.
- cULus Listed and meets ANSI / NSF 61 standards for safety and water quality.
