American Standard® 4A6L9036A1000B 3.0T SPL SIDEDISCHARGE HP 1PHS VARSPD
American Standard® 4A6L9036A1000B 3.0T SPL SIDEDISCHARGE HP 1PHS VARSPD
Manufacturer: Trane International Inc
Brand: American Standard®
Part #: 385196
MPN: 4A6L9036A1000B
Customer Part #:
Min. Order Qty: 1
Login for Availability
Login for Price
| Airflow CFM | : | 2,400 |
| BTU Rating | : | 36,000 Btu/hr |
| Blower Fan Speeds | : | Variable |
| Charging Specification Subcooling | : | 10 Deg. F |
| Coil Face Area (Sq-Ft) | : | 12.88 |
| Coil Rows | : | 2 |
| Coil Type | : | Plate Fin |
| Compressor Heat | : | Yes |
| Compressor Insulation/Sound Blanket | : | Yes |
| Compressor LRA | : | 48.9 |
| Compressor Power Rating | : | 208-230/1/60 |
| Compressor RLA | : | 12.4 |
| Compressor Type | : | Duration - Scroll |
| EER2 | : | 12 |
| ElecHertz | : | 60 |
| ElecPhases | : | 1 |
| ElecVolts | : | 208-230 |
| Factory Charged | : | Yes |
| Factory Installed Start Components | : | No |
| Fan Diameter (In) | : | 27.5 |
| Fan Drive | : | Direct |
| Fan Motor FLA | : | 2.3 |
| Fan Motor HP | : | 1/2 |
| Fan Type | : | Propeller |
| HSPF2 | : | 7.5 |
| HSPF | : | 10 |
| Line Size Gas | : | 3/4 |
| Line Size Liquid | : | 3/8 |
| MCA | : | 26.9 |
| Max Amps | : | 30.0 |
| Max Fuse | : | 30 |
| Max SEER2 | : | 18.5 |
| Max SEER | : | 18 |
| Min SEER2 | : | 15.2 |
| Min SEER | : | 14.25 |
| Motor (RPM) | : | 200 to 1,050 |
| Motor Power Rating | : | 325-385/3/60 |
| Nominal Capacity BTU Rating | : | 36,000 |
| Number of Compressor | : | 1 |
| Number of Fan Motors | : | 1 |
| Number of Fans | : | 1 |
| Number of Stages | : | Single Stage |
| Outdoor Coil-Tube Size (In) | : | 3/8 |
| Phase | : | 1.0 ph |
| Power Supply | : | 208-230/1/60 |
| Product Name | : | Split Heat Pump |
| Refrigerant Charge lbs | : | 8 |
| Refrigerant Type | : | R-410A |
| Rows Per Inch | : | 16 |
| SEER2 Range | : | 14 |
| Sound Level | : | 70 dBA |
| Specifications1 | : | SEER:: 19|SEER2:: 15.2|Sound Rating (dB):: Not Found|Split System Connection:: Brazed|Stages:: Variable|Tonnage:: 3 |
| Tonnage | : | 3.0 Ton |
| Voltage | : | 208/230V V |
