Airguard® Xtreme+Plus® 0474825 Standard Capacity Self-Supported Filter, Die-Cut Panel Filter, 8 MERV, 25 in Length
Airguard® Xtreme+Plus® 0474825 Standard Capacity Self-Supported Filter, Die-Cut Panel Filter, 8 MERV, 25 in Length
Manufacturer: PARKER HANNIFIN CORP
Brand: Airguard®
Part #: 385062
MPN: 0474825
Customer Part #:
Min. Order Qty: 1
Login for Availability
| CFM Airflow | : | 2170 cfm |
| Disposable | : | Yes |
| Filter Material | : | Synthetic |
| Filter Type | : | Die-Cut Panel |
| Final Resistance | : | 1 in-WG |
| Frame Material | : | Beverage Board |
| Function Type | : | Filter |
| Initial Resistance | : | 0.22 in-WG |
| Length | : | 25 in |
| MERV | : | 8 |
| Micron Rating | : | 3 to 10 um |
| Product Family | : | Xtreme+Plus® |
| Thickness | : | 2 in |
| Width | : | 25 in |
The XTREME+Plus® standard-capacity, self-supported pleated (SSP) air filter with Airguard® technology achieves MERV 8 mechanical efficiency and provides low pressure drop and industry-leading dust-holding capacity. The filter has over 140 adhesion points between the media and the die cut frame. The inside of the frame is completely coated with water-repellent adhesive to ensure a solid bond at all points of contact with the media pack. The pack is sealed inside the frame and pleat tips are bonded to the stabilizers and diagonal support members. This prevents movement, bunching, and collapsing during operation, which can often cause alternative filter products to fail prematurely. With no metal wire backing to warp or deform, along with a single-piece, heavy-duty beverage board frame and rugged self-supported pleat technology, the XTREME+Plus® filter is capable of maintaining its performance and structural integrity in wet or humid conditions. This saves users time and money that is often wasted on replacing damaged wire-backed filters. XTREME+Plus® pleated air filters are designed for use in commercial HVAC applications with normal operating environments and low to medium dust loading conditions. They are not recommended for use in high-temperature or turbulent-airflow environments.
Airguard® Standard Capacity Self-Supported Filter, Die-Cut Panel Filter, 8 MERV, 25 in Length, 25 in Width, 2 in Thickness, Synthetic Filter, 2170 cfm, 0.22 in-WG Initial Resistance, 1 in-WG Final Resistance, 3 to 10 um Micron Rating, Disposable: Yes, Beverage Board Frame, Product Family: Xtreme+Plus®, Filter Function Type
- Self-supported media - no metal wire backing means no corrosion or deformation of metal
- Consistent pleat shape and spacing allow particulates to collect evenly over the entire surface of the media. Pleat stabilizer straps add rigidity and maintain proper pleat spacing.
- Over 140 adhesion points between the media and the frame
- Achieves MERV 8 mechanical efficiency
- Synthetic media is resistant to moisture, mold, and mechanical damage
- Fully incinerable, environmentally friendly disposal
- Filtration efficiency: MERV 8, MERV-A 8-A
- Nominal thickness (in.): 1, 2
- Rated air velocities (fpm): 300-500
- Initial resistance (in.w.g.): 0.15-0.22
- Final resistance (in.w.g.): 1.0
- Maximum operating temperature: 150 deg F (65 deg C)
- Material of construction: single-piece, moisture-resistant, beverage board frame
- Classified per UL Standard 900 for flammability
