Airguard® Xtreme+Plus® 0474602 High-Capacity Self-Supported Filter, Die-Cut Panel, Pleated Filter, 8 MERV, 16 in Length
Airguard® Xtreme+Plus® 0474602 High-Capacity Self-Supported Filter, Die-Cut Panel, Pleated Filter, 8 MERV, 16 in Length
Manufacturer: PARKER HANNIFIN CORP
Brand: Airguard®
Part #: 385021
MPN: 0474602
Customer Part #:
Min. Order Qty: 1
Login for Availability
| CFM Airflow | : | 1400 cfm |
| Disposable | : | Yes |
| Filter Material | : | Synthetic |
| Filter Type | : | Die-Cut Panel, Pleated |
| Final Resistance | : | 1 in-WG |
| Function Type | : | Filter |
| Initial Resistance | : | 0.15 in-WG |
| Length | : | 16 in |
| MERV | : | 8 |
| Micron Rating | : | 3 to 10 um |
| Product Family | : | Xtreme+Plus® |
| Thickness | : | 4 in |
| Width | : | 25 in |
XTREME+Plus® HC (high-capacity) self-supported pleated (SSP) air filters are specially designed for high performance and extended service life in HVAC or process air applications with low or medium dust-holding requirements. All XTREME+Plus® HC filters achieve MERV 8 mechanical efficiency and feature a state-of-the-art media pack surrounded by a single-piece, beverage board die-cut frame. The filters can endure impact and deformation and return to their original shape, saving users time and money that is often wasted on replacing damaged wire-backed filters. With over 250 adhesion points between the media and the frame, the XTREME+Plus® HC resists movement, bunching, and collapsing during operation thus supporting a consistent low pressure drop, balanced dust-loading, and extended service life. With no metal to warp or deform and rugged self-supported pleat technology, the filters are capable of maintaining their structural integrity even in humid or wet conditions. XTREME+Plus® HC pleated air filters are not recommended for use in applications with high temperatures or turbulent airflow conditions.
Airguard® High-Capacity Self-Supported Filter, Die-Cut Panel, Pleated Filter, 8 MERV, 16 in Length, 25 in Width, 4 in Thickness, Synthetic Filter, 1400 cfm, 0.15 in-WG Initial Resistance, 1 in-WG Final Resistance, 3 to 10 um Micron Rating, Disposable: Yes, Product Family: Xtreme+Plus®, Filter Function Type
- Self-supported media - no metal wire backing means no corrosion or deformation of metal
- Consistent pleat shape and spacing allow particulates to collect evenly over the entire surface of the media. Pleat stabilizer straps add rigidity and maintain proper pleat spacing.
- Over 250 adhesion points between the media and the frame
- Achieves MERV 8 mechanical efficiency
- Synthetic media is resistant to moisture, mold, and mechanical damage
- Fully incinerable, environmentally friendly disposal
- Filtration efficiency: MERV 8, MERV-A 8-A
- Nominal thickness (in.): 1, 2, 4
- Rated air velocities (fpm): 300-500
- Initial resistance (in.w.g.): 0.13-0.18
- Final resistance (in.w.g.): 1.0
- Maximum operating temperature: 150 deg F (65 deg C)
- Material of construction: moisture-resistant beverage board frame
- Classified per UL Standard 900 for flammability
